Detailed specifications of the M5 Smart

Detailed specifications of the M5 Smart

Series

M Series（Mid-Range）

Recommended Users

Moms with multiple breast pumps

Series Keywords

High Efficiency
Great Mobility

Model Keywords

Smart Control
High Efficiency
Comfortable Pumping

Color

White

Motor

/

Default Flange Size

24mm

Maximum Suction Power

285mmHg

Flange Size for Purchase

/

Meal Collector Capacity

160ml/5.4oz

In-Package Insert Size

17mm/19mm/21mm

Milk Level Reminder

120ml

Insert Size for Purchase

/

Pumping Level

9 Levels

Usage Time

180 minutes/6 sessions

Mode

Stimulation, Express, Mixed

Charging Time

120 minutes

Working Sonud

≤48dB

Charger

5V/1A

Packaging Dimensions

(Double)

28.1 x 11.1 x 17.9 cm
11.1 x 4.4 x 7.0 in

Operation Voltage

DC 3.7 V

Packaging Weight
(Double)

1.20 kg
2.65 lbs

Battery Capacity

1400mAh

Packaging Dimensions
(Single)

17.8 x 11.2 x 15.4 cm
7.0 x 4.4 x 6.1 in

Pump Dimensions

128mm×117mm×74mm

Packaging Weight
(Single)

0.70 kg
1.54 lbs

Pump Weight

232g

All-in-one or not

√

Valve

Duckbill Valve

LED Display

√

Screen Lock

60 seconds

Charging Case

√

Auto Shut Off

30 minutes

Smart Pumping Rhythm

×

Usage Life

500 hours

Pumping Frequency

×

Ease of Use

4 Cleaning Parts

Time setting

×

Replacement Duration for Silicon Accessories

1~3 months

APP Control

×

Replacement Duration for Milk Bottle and Flange

1~3 months

Bottle Stored Independently

×

Flange Insert compatibility

M5/M5 Smart/M6/M9/S12 Pro Quick/V1 Pro/V2 Pro/Air 1

Single/Double Pumps Usage

√

Operating Condition

Temperature: 0℃ to 40°C
Humidity: 15% to 90%
Atmospheric Pressure:70kPa to 106kPa

Vacuum range

Stimulationmode: -75 to -145(±30)mmHg
Expression mode: -120 to -285(±30)mmHg
Mixmode: -75 to -285（±30)mmHg

Transportation&
Storage environment



Temperature: -20℃ to 60°C
Relative Humidity: 15% to 90%
AmbientPressure: 70kPa to 106kPa

Cycle speed

Stimulationmode: 50~120（±2)cycle/min
Expressionmode: 23~57(±2)cycle/min
Mixedmode: 6~16(±2)cycle/min
