Detailed specifications of the M9

Detailed specifications of the M9（BP223）

Series

M Series（Mid-Range）

Recommended Users

Experienced Moms

Series Keywords

High Efficiency
Great Mobility

Model Keywords

APP Control
Powerful Suction
Smart Custom Modes

Color

Cozy Red,Quill Grey

Motor

3rd Generation

Default Flange Size

24mm

Maximum Suction Power

300mmHg

Flange Size for Purchase

24mm/27mm

Meal Collector Capacity

150ml/5.2oz

In-Package Insert Size

17mm/19mm/21mm

Milk Level Reminder

120ml

Insert Size for Purchase

15mm/17mm/19mm/21mm

Pumping Level

15 Levels

Usage Time

150 minutes/4-5 sessions

Mode

Stimulation, Express, Mixed

Charging Time

150 minutes

Working Sonud

≤48dB

Charger

5V/2A

Packaging Dimensions

(Double)

27.7 x19.0 x15.3 cm
10.9 x7.5 x6.0 in

Operation Voltage

DC 3.7 V

Packaging Weight
(Double)

1.67 kg
3.68 lbs

Battery Capacity

1800mAh

Packaging Dimensions
(Single)

17.6 x16.4 x15.5 cm
6.9 x6.5 x6.1 in

Pump Dimensions

127mm×109mm×77mm

Packaging Weight
(Single)

0.89 kg
1.96 lbs

Pump Weight

302g

All-in-one or not

√

Valve

Duckbill Valve

LED Display

√

Screen Lock

60 seconds

Charging Case

×

Auto Shut Off

30 minutes

Smart Pumping Rhythm

Milk Boost^TM, Milk Relief^TM

Usage Life

500 hours

Pumping Frequency

×

Ease of Use

4 Cleaning Parts

Time setting

×

Replacement Duration for Silicon Accessories

1~3 months

APP Control

√

Replacement Duration for Milk Bottle and Flange

1~3 months

Bottle Stored Independently

√

Flange Insert compatibility

M5/M5 Smart/M6/M9/S12 Pro Quick/V1 Pro/V2 Pro/Air 1

Single/Double Pumps Usage

√

Operating Condition

Temperature: 0℃ to 40°C
Humidity: 15% to 90%
Atmospheric Pressure:70kPa to 106kPa

Vacuum range

Stimulationmode: -67 to -172mmHg
Expression mode: -105 to -300mmHg
Mixmode: -105 to -300mmHg

Transportation&
Storage environment



Temperature: -20℃ to 60°C
Relative Humidity: 15% to 90%
AmbientPressure: 70kPa to 106kPa

Cycle speed

Stimulationmode: 62~90cycle/min
Expressionmode: 26~66cycle/min
Mixedmode: 50~85cycle/min
